There's another reason if we consider it in terms of interior design. It's related to directionality, the space is always divided into two parts. Whether it's a moving space or a staying space, but if we want to use it most efficiently...

Hi, Watson! Now today, let's talk about “why there are so many rectangular buildings?” If you look around, most of the buildings are in the form of boxes, and if you look at the representative apartment buildings in Korea, they are rectangular.

If you ask me why, I think there are three or four main reasons. The first reason is the economy. If you imagine when buildings were built in the past, all of our buildings are made of wood. And four wooden pillars are used.

And on the four pillars, the roof needs to be on top. To support the roof, the wooden supports that are named ‘보(bo)’ in Korea are needed on pillars. In fact, the wooden supports are more powerful than pillars when constructing buildings.

For example, let's say we're holding a matchstick. When you press it from the top like this way, regarding this as a matchstick, If you press it like this, it doesn't break easily. But if you break it like this, it breaks!

The wood doesn't break well if you compress it when it's in this vertical direction, but it breaks well if you turn it 90 degrees to the side. What that means is that the wooden supports are more likely to break than the wooden pillars.

So that is the reason why we need to use stronger wooden supports. So the most expensive and best tree for building is used for wooden supports. That's why I used to watch wooden support as a reference point to determine how rich people live in Korean TV shows.

So there's a problem that we have to use a big tree for the wooden supports. That's why we need to use the wooden supports more efficiently. Since a person's average height is only 5 to 6 feet, so the wooden pillars are needed to be about 6 feet 5 inches.

So we use short trees. But the wooden supports that support the building need to use longer trees, and the question is how to adjust the length. Let's say we went to the forest and cut down the trees. But some trees are long and some trees are short. There must be trees of various lengths.

I don't think that all trees have the same length. Then the carpenter has to decide. If we want to make a square building, all four wooden supports have to be the same length. Then guess what will happen? We have to cut the other three according to the smallest length.

Then it's a huge waste. In this situation, the architect thinks like this. There is only one way to waste the least. As you can see, these two have to be the same length. So cut the long one according to the short one of the two longest ones, and cut the third one according to the length of the third and fourth one.

Then two long ones come out and two short ones come out. If we make wooden supports with two long ones and two short ones, we can make a rectangular wooden support as you can see like this. So this becomes the structure that supports this building.

So, as you can see, for economic reasons, we make two for long and two for short, and that results in a rectangular plane. That's the first reason. The second reason is directionality. All spaces, in fact, get their directionality depending on the given conditions.

There are few cases where the width and length are composed of the same length. We can think of Manhattan as an example. We call the road in the north-south direction "avenue". The avenue is wide and open in a straight line. Starting with First Avenue, it's numbered to 10th Avenue.

On the other hand, the one that goes vertical to that is called "street". The street is very narrow. Instead, it's tightly placed. The reason is that if you look at the island called Manhattan, the island is long in the north-south direction.

That's why a long street in the north-south direction should be the main road. There must be more traffic in the north-south direction. The east-west direction is narrow. So the street is narrow because there is little traffic.

So the main traffic is going to the avenue, and then when you come to the street, you just have to get out of the street you want. If a space has a direction and is long in the vertical direction, there is a main road axis according to it.

Anyway, the direction is determined according to the shape of the land. Because of that, a certain direction is long and a certain direction is short, an axis like this is created. So buildings are also more efficient in rectangular form. And the third reason is that if it's a rectangle, it's good to get sunlight.

Let's say we're building a house that's 100 square meters, and what happens if we make this square in the forward direction is that the sun rises in the east and sets in the west. So we know that the south side is the most sunlit part, so if we make it square, it's only 10 meters under the sun.

But if it's just 100 square meters, if you make it long horizontally, the length of the side facing south can be much longer. That means you can stay warmer in the winter. If you ask if it's a problem because it's hot in summer, we can just pull out the eaves long.

Then we can block the summer sun. Another advantage is that if we make a square like this, the area where the sun comes in will end up just to this much. So this background is bound to be a dark space.
But if you make it long horizontally, sunlight comes in on almost every side.

So, the longer we make a building in the east-west direction,
the more advantageous we can make a building in heating or lighting. Then you can ask this question, "if the sun goes up,
if it goes up in a circle, don't you think you can make the surface round?"

If you apply it here,
the half of the circle will be a zone where the sun doesn't come in.  So, in fact, it has the advantage of being able to receive sunlight
much more effectively when it's made into a rectangle than a circle.

But there's another reason in terms of the interior design.
It's also related to directionality. The space is always divided into two parts.  Whether it's a moving space or a staying space, and what is a moving space, it is like a corridor. And the places you stay are like
living rooms and classrooms.

If you think of the school, it's horizontally long.
The sunlight has to come into the classroom well, so it's facing south. But if you look there, there's always a corridor in the north and a corridor in the middle.

If the floor plan is like this, you can see the hallway in the back and the classrooms are divided toward the south. So this classroom is a place to stay, and this hallway is a place to move.
You move from side to side in the hallway and go into the classroom to live.

But in order for us to use space most efficiently,
the least amount of space to move is the most efficient. If this space is close to the right direction, we have to double-hole the hallway like south-north and east-west. That's why there's a situation where four classrooms are split up like this.

But if we make this into a rectangle, we just have to put it in the hallway on one side where the sunlight isn't good and pierce it like this. So we can use the space more efficiently. If this goes to a smaller room, every room actually needs space to travel and stay in it.

When I put the furniture, when I put the bed or the desk,
the desk is actually a rectangular shape, right? Because even if you make it square, you can't use the space in front of you where you can't reach your arms.

The space that I actually read books or write in my notebook is only about 2 feet wide from my chest. So there's no reason to make it wider than that. If you put a rectangular desk and a rectangular bed in a square shape, there's a lot of space that's thrown away like this.

But if this space is kind of like this...
Then there's a space where you can use it more efficiently.  So we're usually made of rectangles, and everything that we do actually starts on a human scale, and our body is also shaped like a long rectangle up and down.

And when you move, it's often rectangular.
Because cars are rectangular and the reason why they are is that they have a direction to move forward, so we don't make them long in the east-west direction. There's a direction of people in the direction of movement.  All the objects we use whether they’re moving or staying, they are shaped like rectangles like this.

So when we put them in a rectangular space, we can see that it's easy to put them in one by one. But there are buildings that are not rectangular.  As I explained before, the circular space is very inefficient.
As I said in a previous video, power is created when there’s a waste.

So on the contrary, the prototype of the wasteful planes can be a design that represents authority or proves that there is power.  So, if you look at the Pantheon, it's a circular structure and there's a building called Temple of Heaven where rituals are held in China.

If you look at those, they’re shaped in a circle.
And there are many cases where religious structures are circular.  It's because it's basically a space that's not used in everyday life.
But in the case of the chapel, it's rectangular.

Because it's the most efficient way to make the biggest space because there's a functional reason why many people have to gather. If you look at the most representative churches in Europe, most of them have rectangular floor plans and chairs. There's a foundation on the front

If you imagine when they make this, the size of this building is decided by the strength of the building material that can make the space between the columns. And if you look at the cross section, they have to make a pillar and the roof needs to go in. Then, the roof goes in an upside down V shape.

For example, let's say we brought the longest member of the framework. If you stack two of them in an upside down V shape, the width of the building comes out. Then we decide on the width of the tree that we can get, and the length of the tree called 'a' now determines the width of this building called 'b',

and then if we copy this system called 'a' in one direction, the length of the building called 'c' comes out. Therefore, this is the most effective way to create a large space. That is because it's bound to be a rectangle. So what they did during the Roman period is a building called the Basilica. The Basilica was used as a market or as a presiding judge's court.

So, it's a space where a lot of people need to go to trial or gather around as an indoor space. But suddenly, when Christianity became a state religion in Rome, many people had to gather in the chapel. So where is the biggest place to gather? The Basilica.

So they gathered in the Basilica and worshiped, and the Basilica was made with this roof based on the principle that I mentioned and copied it to one side. But this isn't too religious. Since it's not religious, so they decided to make a dome for this like many other religious architectures that was shaped in a circular form, wasting space.

So they put the dome of the Pantheon over here. And the dome on the floor plan of the Basilica is typical of St. Peter's Basilica or something like that. Also, they thought it would be better to have a floor plan symbolizing a cross than a straight one, so they made a floor plan in the shape of a cross.

and get domes at the intersection of the two horizontals and verticals is now the prototype of a common chapel. Because of the movement line system I mentioned earlier,
it's inevitable to come out as rectangles when we make a building. Anyway, if we want to use this interior space, we have to move from a to b space, then there's bound to be a hallway.

If we make it square, it'll be hard to divide the space. And it's easy to get a room without windows. In order for the window to somehow contact the outside air and improve lighting and ventilation, it is better to make it rectangular.

If not, it is the case of using one large room like a gym or a stadium. We don't have to worry about such things in these cases. It's a structure that surrounds the surrounding area to watch
the main event in the middle,

so in that case, we don't divide the interior space
and use it for various purposes. So, when we design an art museum or a stadium, we have to think that the approach is different. So, of course, the shape is bound to come out differently.

So this time, we have talked about why there are so many rectangles in the building. And let's continue to talk about something else next time.

[EN] 🙋‍♂️"건물은 왜 직사각형인가요?" 기출문제로 나올 것 같은 건축과 교수님의 명쾌한 답변..!

유현준의 유튜브입니다~
#유현준 #공간 #도시 #건축
🔍 공간으로 세상을 이야기합니다  🔍



셜록현준

네 개의 기둥과 나무 지지대('보')를 사용한 전통 목조 건축입니다.

목재는 수직으로 압축할 때 더 강해지므로 지지대를 효율적으로 사용할 수 있습니다.

나무 길이가 다양하기 때문에 낭비를 최소화하려면 직사각형 모양이 필요합니다.

직사각형 구조는 다양한 길이의 나무 지지대를 사용하여 낭비를 최소화합니다.

직사각형 모양은 사용 가능한 재료를 가장 경제적으로 사용할 수 있는 방법입니다.

맨해튼의 그리드 시스템은 방향성이 건물 모양에 어떤 영향을 미치는지 잘 보여줍니다.

건물은 방향 축으로 인해 직사각형 형태가 더 효율적입니다.

직사각형 모양은 햇빛 노출을 최적화합니다.

인테리어 디자인 및 공간 효율성

방향성은 공간을 이동 공간과 체류 공간(복도 대 방)으로 나눕니다.

직사각형 모양은 동선 공간을 최소화하여 공간 활용도를 극대화합니다.

직사각형 가구는 직사각형 공간에 효율적으로 어울립니다.

직사각형 모양은 사람의 움직임 패턴과 물체 모양에 맞춰 정렬됩니다.

원형 건물은 효율성은 떨어지지만 권력이나 권위를 상징할 수 있습니다.

판테온과 천국의 신전 등이 그 예입니다.

종교 건축물은 원형을 사용하기도 하지만 예배당은 효율적인 공간 활용을 위해 직사각형인 경우가 많습니다.

바실리카의 직사각형 모양은 초기 기독교 교회에서 효율적인 대규모 집회를 위해 채택한 것입니다.

건물 크기는 재료의 강도와 기둥 사이의 공간에 따라 결정됩니다.

바실리카의 디자인은 공간을 효율적으로 최대화하여 직사각형 모양을 만들었습니다.

바실리카의 적응력은 기독교에 의해 채택되었습니다.

나중에 돔이 추가되었지만 직사각형 평면도는 중앙에 그대로 유지되었습니다.

십자가 모양의 평면도가 교회에서 일반화되면서 직사각형 형태가 더욱 굳어졌습니다.

건물 내 이동을 위해서는 복도와 직사각형 레이아웃이 필요합니다.

직사각형 모양은 자연 채광과 통풍이 용이합니다.

체육관이나 경기장과 같은 넓은 단일 목적 공간은 직사각형 모양에서 벗어날 수 있습니다.

특수 건물에는 직사각형 형태를 따르지 않는 독특한 설계 방식이 필요합니다.
