3D Printing & Painting a Duck Tube and Sweet B Toy using Nomad Sculpt & Water-Washable Resin

안심팩토리의 제선 씨가 노매드 스컬프트와 물 세척이 가능한 레진을 사용해 3D 프린팅으로 오리 튜브와 스위트 비를 제작하고 있습니다.

### 아이패드와 3D 프린터로 아트토이 만들기: 덕튜브와 스윗B 제작기
* 🎨 안심팩토리 지선님이 **Nomad Sculpt** 앱을 사용하여 아이패드로 덕튜브와 스윗B 아트토이 모델링 과정을 소개합니다.
* 💡 처음으로 **수용성 레진**을 사용하여 3D 프린팅을 시도하며,  3년 전 구매한 Anycubic Photon Mono (2K 해상도) 3D 프린터를 사용했습니다.
* 💦 수용성 레진 세척 과정에서의 어려움과 수정 과정을 보여주며,  세척 미흡으로 인한 얼룩 문제와 해결 과정을 상세히 설명합니다.
* ⚙️ 프린팅 후 **IPA 대신 물로 세척**하는 과정과 4배속 편집된 프린팅 영상을 공개하며,  최종적으로 깨끗한 세척 결과물을 얻습니다.
* 🖌️ **아크릴 물감**을 사용하여 아트토이에 채색하며, 에어브러쉬와 붓을 병행하여 섬세한 디테일 작업을 진행합니다.
* ⏱️ 약 3개월 만에 완성한 아트토이에 **샌딩 및 마감 작업**을 거치며,  습식 사포를 사용하여 먼지 발생을 최소화하는 팁을 공유합니다.
* ✨ 파스텔, 색연필 등을 활용하여 입체감과 디테일을 더하고,  **세미글로스와 무광 코팅**을 통해 완성도를 높입니다.
* 😭 아크릴 물감이 쏟아지는 예상치 못한 사고에도 굴하지 않고 완성된 아트토이를 전시하며 영상을 마무리합니다.

Hello, this is Jesun from Ahnsim Factory. Today, I'm showing you how to make a 'Duck Tube and Sweet B'.

All the models on my channel are made using the iPad app 'Nomad Sculpt'. I use it for more than just modeling,

and I'll share more about that later! This time, I'm making this for myself,

so I experimented a lot.  As a result, I made a lot of mistakes.

Please enjoy watching! After modeling, you need to prepare the model for printing.

I'm trying water-washable resin for the first time. I filmed the whole process.

Many people worry about the strong smell and harmful chemicals in toy-making, and I'm sensitive to smells too,

so I'm gradually switching to safer materials. (Here I am, not even wearing gloves… feeling a bit sheepish)

Many people have asked about my 3D printer. I bought it about 3 years ago, and it's discontinued now.

It was Anycubic's Photon Mono, the basic model. It was 2K resolution... now you can get 14K models. (K refers to resolution)

Technology is amazing! Haha... I couldn't keep up, so I sped up the video 4x.

Aghhhhhhh!! The print is complete. After printing, you need to clean the excess resin with IPA,

but it has a strong smell and is harmful. This resin is water-washable, and after washing, I cure it normally.

Since it's my first time, I messed up the cleaning and it's blotchy.

I can't believe it's real... Time for a quick fix. This part got stuck during assembly.

I should have checked it in the final stage, but I was too hasty. After fixing the caught part,

I created the output file and printed only the duct tube. Again, after washing, I cured it.

The one on the right is the previous print, and the one on the left is the current one.

This time, the washing was successful. It turned out much cleaner than before. Haha! Stiff… but at this point, I had no intention of painting it.

As long as it fits, I'm good!! said my past self. I was excited to have two tubes

and even tried putting in another bear. About three months later… I decided to finish it for a YouTube video.

To finish it, I sanded it down. Using wet sandpaper reduces dust, which is nice.

I changed the sandpaper and continued sanding thoroughly in order. I can tell the level of sanding just by the sound at this point.

I also cleaned up the bumpy support spots left on the print. When I make a copy, I sand very carefully,

but since this is for me, I did it roughly 😆 This should do. To be honest, you shouldn't fix it like this,

but instead make it stable so it doesn't show. The theme of this project is "just get it done."

I did a base coat for the first layer and checked for missing spots before doing 2-3 more coats.

I'm nervous it might fall off. I'm using acrylic paint, so there's almost no smell.

However, maintaining the airbrush is very difficult, and foreign particles sometimes get mixed in. So there are many things to be cautious of while painting.

It has its pros and cons. I painted the overall surface with an airbrush and used a brush for the smaller details.

I have to paint it multiple times. I also tested a new acrylic paint this time, and it seemed good, so I'm going to use it some more.

I'm painting the eyes now, but as a newbie YouTuber, I often forget the camera while focusing.

Ta-da! I'll paint the duck's eyes the same way. Somehow, it feels like I just took off my glasses...

I'll make the eyes a bit bigger. I was listening to music with earphones, but the sound was all captured by the camera.

(Is my eardrum okay?) Once all the painting is done, I use pastels for additional touches.

Using a brush, I add blush and shadows for more detail.  For the duck's beak, I add natural shading and blush too.

I was a bit surprised when it clumped up. I use a smaller brush for more detail.

For the final touch, I add texture with colored pencils. I should have used an orange colored pencil, but I didn't have one, so I used red instead.

I applied it lightly so it wouldn't be too strong. Finally, I apply the topcoat.

There are three types: semi-gloss, gloss, and matte. Sweet B is first coated with semi-gloss,

then finished with a matte coat. Mr. Duck is coated with glossy varnish to make him shiny.

While drying, I started cleaning my desk, and disaster struck. I hadn't closed the lid properly, and the acrylic paint I just bought spilled everywhere.

Disaster number two. I was worried, and as expected, the paint on the leg chipped off.

But it's okay. I can do it again. (I wasn't stressed at all) And it's complete!!!!!

Hehehe! I'll put it in the display case. The happiness of being able to create a character that was in my head instantly.

Welcome, new friend! Goodbye! Cookie video: Music I listened to while working!

아이패드로 모델링하고 3d프린터로 아트토이 만들기 (nomad sculpt)

안심팩토리_지선

아트토이 제작 과정 소개 및 준비

아이패드 앱 Nomad Sculpt를 이용한 모델링 과정 설명

개인적인 제작 목표 및 시행착오 언급

3D 프린팅을 위한 모델 준비 및 수용성 레진 사용

사용 3D 프린터(Anycubic Photon Mono) 소개 및 기술 발전 언급

프린팅 완료 후 IPA 세척 및 경화 과정

수용성 레진 세척 과정의 어려움과 수정 과정

조립 과정에서 발생한 문제점과 해결 과정

덕트 튜브 재프린팅 및 성공적인 세척

사포질을 이용한 표면 다듬기 및 먼지 감소

지지대 자국 정리 및 대략적인 마무리

아크릴 물감을 사용한 도색 과정

마무리 작업 (파스텔, 색연필, 코팅)
