Introduction to Witcher 1 XR Glasses and Their Features

The Witcher 1 XR glasses serve as a versatile external monitor requiring a compatible device for optimal use.

### Introducing the Witcher 1 XR Glasses: Features and Setup Guide
* 👓 Welcome to Victor Academy, where we explore the Witcher 1 ecosystem, starting with the **Witcher 1 XR glasses**, which function as an **external monitor** for compatible devices.
* 🔌 To use the XR glasses, they must be connected to a device that supports **DisplayPort video over USB-C**, such as the Samsung Galaxy S9 or newer, Valve Steam Deck, and various modern laptops and tablets.
* 📦 Inside the box, you'll find the XR glasses, a zipper case, multiple nose pads, a **1.10 cm cable**, and an **anti-clip hair cover**, designed for **user comfort and convenience**.
* 🎛 The glasses feature a mode button for switching between various settings, including **activating the electrochromic film**, adjusting **volume or brightness**, and toggling between **2D and 3D display modes**.
* 🔧 Users can also adjust the virtual image for myopia using rotary knobs above each lens, ensuring a **clear display tailored to individual vision needs**.
* 📱 Once connected, you can enjoy various activities like gaming or streaming, transforming your experience into a **personal home theater setup**.
* 🛡 For protection, store the XR glasses in their zipper case when not in use, and look forward to our next video, which will cover **pairing the glasses with the Victor neckband** for an **enhanced entertainment experience**.
* ❓ For further information and support, visit our **FAQ page** and comprehensive guides at victor.com.

[Music] Thank you. Welcome to Victor Academy. This video series was created to provide an introduction to the many devices offered in the Witcher 1 ecosystem. In our first installment, we'll be reviewing the Witcher 1 XR glasses. Let's get to it.

At their most basic function, the Witcher 1 XR glasses behave like a typical external monitor that you might use to extend the display of, let's say, your laptop. And just like an external monitor for your computer, they need to be plugged in to a compatible device in order to use them.

These XR glasses, you'll need to connect them to a source device that supports DisplayPort video over USB-C. For example, various mobile phones such as the Samsung Galaxy S9 or newer, certain handheld gaming devices such as the Valve Steam Deck and GPD Win 4, many iPads and MacBooks, and some modern Windows laptops. In other words, these XR glasses will not power on nor offer any sort of display unless they are connected to a device that can provide power and video output. Don't have a compatible device? Don't worry, you can

pair the Witcher 1 XR glasses with the Witcher neckband for an all-in-one entertainment experience. Or for a list of some devices that we're confident will be compatible with the Witcher 1 XR glasses, visit witcher.com

forward slash compatibility. However, please keep in mind that this is not a complete list of all the devices on the market that are compatible with the Witcher 1 XR glasses. To determine whether or not your device supports DisplayPort over USB-C, make sure to review the manufacturer specifications.

you're going to want to look for keywords like alt DP over USB-C or DisplayPort over USB-C. Now be careful, USB standards can be quite confusing. When in doubt, contact the manufacturer of the device you are hoping to use with Witcher in order to

make sure that it does support video over USB-C. Now let's open the box. [Music] Thank you. [Music] Thank you. [Music] Inside you'll find The Witcher 1 XR glasses, a zipper case, The Witcher 1 XR glasses,

four nose pads of varying sizes, one 1.10 centimeter cable, one anti-clip hair cover. Let's take a closer look at the XR glasses themselves. On the left arm of the XR glasses, you'll find a series of buttons. The smaller button, known as the mode button, allows

you to switch between several available modes that the XR glasses can be set to once they are connected to a compatible device. The longer button beside it is the adjustment button. More on that later. Let's first review those modes. One short press of the mode button will

activate or deactivate the electrochromic film. For those of you unfamiliar with this feature, the electrochromic film will darken or lighten the outermost lens. Please keep in mind, although this feature is great indoors and in other low-light environments, it's not intended

to be a one-to-one substitution for our lens shade accessory. If you plan to use our XR glasses while relaxing outside on a sunny day, you may want to consider adding our lens shade to your order and always having it handy by storing them in your Witcher 1 XR glasses case.

Next, with two short consecutive presses of the mode button, you can switch the adjustment button to control either the volume or the brightness. One long press of the mode button, about five seconds, will switch the XR glasses from 2D display mode to 3D display mode.

Another long press will switch the display back. Three short consecutive presses of the mode button will take advantage of the 3DOF sensors in the glasses and allow you to pin the display in virtual space. In other words, when you pin the display, it will stay stationary in

virtual space while you move your head around. This feature will only be available if you've updated your XR glasses firmware to the latest release. Now, remember these modes and functions will not work unless the XR glasses are connected to and powered by a compatible source device. While we're looking at the arms of the

glasses, both sides are equipped with directional speakers powered by Harman audio EFX. And on the right arm of the XR glasses, you'll find the magnetic Pogo port that will provide both power and visual data to the XR glasses from your compatible source device. Moving on to actually

wearing these XR glasses, we have designed our XR glasses so that they can fit almost all face types. However, we understand that no two faces are exactly the same. Therefore, in the box, you will find several nose pads of varying sizes in order to accommodate as many people as

possible. In order to change out the nose pads, simply slide out one pair and slide a new pair in its place. The first time you do this might require a little bit extra force. [Music] Speaking of accommodations, above each lens are rotary knobs that offer support

for adjusting the virtual image up to negative 5 degrees for users with myopia (nearsightedness) when the display is on. Rotate each knob until the image is crystal clear. Speaking of turning on the display, let's plug it into a source device. In this video, we'll be plugging our

Witcher 1 XR glasses into a Samsung Galaxy S10 Plus to start. I take the magnetic end of the 110 centimeter cable and attach it to the XR glasses. Next, I put on the XR glasses. I then plug them into the USB-C port of my source device.

After a few seconds, I'll be able to see the display being sent from my phone. In the case of Samsung Galaxy devices, it will either be Samsung DeX or a simple mirroring of the phone's home screen. Now, let's say this is the first time I'm

using the Witcher 1 XR glasses. When I put them on, it's likely that the image is going to appear blurry or seem like it's double vision. Don't worry, this is not an indication that your brand new XR glasses are defective. All that means is that you need to take

time to adjust the display using the rotary dials I pointed out to you earlier. It's a good idea to turn the myopic rotary dials to one side as far as they can go, put on the glasses, then close one eye and start adjusting the

dial until the image comes into focus. Repeat the step for your other eye until you find that the display has come into focus for both eyes. Also, keep in mind that the Witcher 1 XR glasses can accommodate a pupillary distance range between 58 and 70 millimeters. The most

A reliable way of measuring your pupillary distance is by visiting your optometrist. If your vision demands a very powerful prescription, Witcher 1 XR glasses can be purchased with prescription lens inserts that magnetically attach to the XR glasses like so.

You can take these inserts to your optometrist or eyewear shop and ask them to replace the lens in this frame with ones that match your prescription. We've also partnered with eyewear companies so that you can order your very own custom pair of prescription

inserts. For more information on how to order prescription inserts, visit victor.com. So now that I have the virtual one XR glasses plugged into my phone, what can I do? Well, that's totally up to you. Remember, at their most basic, The Witcher 1 XR

glasses are an external monitor, so at the very least you can save yourself a lot of neck pain by sitting back and interfacing with your phone without having to look down. About to take a long trip? Connect The Witcher 1 XR glasses to your Steam Deck

and play the latest titles with a massive HD display right before your eyes. Or start up your favorite streaming service like Disney+ and catch up on your favorite shows, all while sitting back as if you were in your own personal home theater. Finally, when you're all

done, you can keep the XR glasses safely stored in the zipper case along with its cable to avoid any accidental damage. In our next video, we'll pair the Vitra 1 XR glasses with our Victor neckband. When paired together, the Victor 1 XR glasses

and neckband provide an all-in-one entertainment experience that is light enough to wear and take with you just about anywhere you go. And remember, for answers to frequently asked questions, feel free to visit our FAQ page at fitbit.com/FAQ.

Or for more comprehensive guides, instructions, and how-to articles, visit fitbit.com/Academy. There you'll learn more about how to get the most out of your new Fitbit devices.

VITURE One XR Glasses Tutorial | VITURE Academy

VITURE

Introduction to Witcher 1 XR Glasses and Basic Functionality

Video introduces Witcher 1 XR glasses and their function as an external monitor.

Glasses function like an external monitor, requiring connection to a compatible device.

Compatibility requires DisplayPort video over USB-C; compatible devices include various phones, gaming devices, iPads, MacBooks, and Windows laptops.

Alternative: pairing with Witcher neckband for an all-in-one experience; compatibility list available on witcher.com/compatibility.

Check device specifications for DisplayPort over USB-C support; contact manufacturer if unsure.

Unboxing and Physical Features of the Glasses

Unboxing reveals the glasses, case, nose pads, cable, and anti-clip hair cover.

Left arm buttons: mode button (switches modes) and adjustment button (controls volume/brightness).

Right arm features a magnetic Pogo port for power and data.

Various nose pads for different face types; rotary knobs adjust virtual image for myopia.

Modes and Functions of the Witcher 1 XR Glasses

Mode button functions: electrochromic film activation, volume/brightness control switching, 2D/3D display mode switching, and display pinning.

Electrochromic film darkens/lightens lenses; lens shade accessory recommended for outdoor use.

3DOF sensor allows display pinning in virtual space (requires firmware update).

Harman audio EFX powered directional speakers on both arms.

Setting up and Using the Witcher 1 XR Glasses

Connecting glasses to a Samsung Galaxy S10 Plus; initial setup and display adjustment.

Blurry image on first use is normal; adjust rotary dials for focus.

Pupillary distance range: 58-70mm; optometrist visit recommended for measurement.

Prescription lens inserts available; can be customized through partnered eyewear companies.

Uses: external monitor, gaming (Steam Deck), streaming.

Next video: pairing with Witcher neckband for all-in-one experience.

FAQ and further information available on fitbit.com/FAQ and fitbit.com/Academy.
