Terrain Material Blending with Height Maps

Height blending technique is used to blend materials based on their height data, creating smooth transitions for terrain shaders.

### Height Blending: A Technique for Blending Materials in Shaders
* 🏞 "Height blending" is a technique used to blend two or more materials by using their height data to generate a **blending mask**, which is particularly useful when developing shaders for terrains.
* 🗺 A "height map" is a grayscale texture that indicates the **height of a texture** compared to a **hypothetical ground level plane**.
* ⚙ The base concept of height blending is that for every pixel, the **higher height wins and gets displayed**, so a mask is needed that is **black when the first height map is higher** and **white when it's not**.
* 🎚 To create a transition between two materials, a gradient is required that **lowers one height map while raising the other**, and vice versa.
* 🔄 By adjusting the blending algorithm with a **smoothness coefficient**, it is possible to control how **smooth the transition between materials** should be.
* 🏞 "**Height blending**" allows for achieving a higher quality landscape with relative simplicity and can be used in **conjunction with other advanced techniques**.

hi guys in this video we get back to the transition between textures topic. [Music] we're going to discuss a particular way to blend materials, especially useful when developing shaders for terrains. This technique consists in blending two or more materials by using their height data to generate the blending mask. To do so, we'll need a height map for every texture set we want to blend. A height map is a grayscale texture that, with each pixel, tells us how high the texture is compared to a hypothetical ground level plane. [Music] To give you a better visualization of the data, an 8-map represents I made this shader that re-marches and visualizes its values. This data, unlike the one represented by the normal maps, for example, hasn't got a universal convention, and its interpretation usually changes from game to game. For example, a game could consider the black color has a high top 0 and the white color has a height of 1. Another game could consider the middle gray value as a height of 0.

and treat any value below as a depression, and any value above as a mound. Moreover, a game could choose to have all its 8 maps normalized to take advantage of the full texture dynamic range, and then rescale them inside the shader. Another game could consider to define the word values of the 8mp color range and have it already in scale. As you may recall from the video about texture transitions, we already know that the head maps to achieve our gold must be used in some way as input for the larp alphas. The base concept of height blending is that for every pixel, the higher height wins and gets displayed, so we need a mask that is black when the first height map is higher and white when it's not. We can achieve that result by subtracting the first height map from the second one, taking the result sign, and saturating it, eliminating negative values. The result is this mask, which when input to the larp alphas, will give us resultant intersection between the two materials. Now to obtain a transition between these

two materials. We need a gradient that lowers the 1 8 map while erasing the other one, and vice versa. To do so, we'll use the uv channel red component as an example gradient. [Music] First of all, we will saturate and subtract 0.5 from it. [Music] Next, we are going to add it to the second height map and add its inverse to the first one. [Music] In this way, when the gradient is black, our first statement values range from 0.5 to 1.5, while the second ones go from negative 0.5 to 0.5, so the first hate map is always higher. The value ranges are inverted when the gradient is white, where the in-between gradient values are the hate maps have a chance to intersect. [Music] This is a good result, but we can do better. For example, we could want to be able to choose how smooth the transition from a material to another has to be. To achieve that, we have to slightly adjust our blending algorithm. The sine node must be replaced by a

division by a smoothness coefficient, followed by an addition of 0.5. [Music] The heat blending allows us to reach a higher quality in our landscape with relative simplicity, and it can be used in conjunction with other advanced techniques, which will be discussed in future videos. You

Height Blending Material Layers [UE4, valid for UE5]

Hi,

I'm a Senior Technical Artist, specialized in Shaders, VFX, Procedural Content Generation and any cool visual stuff that has been working in the video game industry for several years.

I've always been passionate about teaching and I want to share my knowledge in form of tutorials using this channel.
I cover basic and advanced stuff, always spiced with some extra stuff that usually is never explained in standard tutorials.

Visual Tech Art

Blending Materials with Height Maps for Texture Transitions

Blending materials using height data creates a smooth transition between textures, with each pixel's height map determining the blending mask.

The interpretation of height map data can vary between games, leading to different conventions for color representation and value scaling.

The blending process involves subtracting the first height map from the second, using the result to create a mask for the texture intersection and achieve a seamless transition.

Blending Materials with a Gradient in 3D Design

The process involves using the red component of the uv channel as a gradient to lower one map while erasing the other.

5 from it, then adding it to the second height map and adding its inverse to the first one, a smooth transition between materials is achieved.

Replacing the sine node with a different function allows for the adjustment of the transition's smoothness, providing more control over the blending algorithm.

The Impact of Heat Blending on Landscape Quality

Heat blending improves landscape quality with a simple process and the addition of 0.

It can be combined with other advanced techniques for even better results, as discussed in future videos.
