Growing Human Bones: Advances in Regenerative Medicine

Scientists are developing methods to grow customized human bones using patients' own stem cells in bioreactors.

### Growing Human Bones Outside the Body: A Potential Breakthrough in Bone Regeneration
* The process of bone growth begins in a fetus as soft cartilage, which is gradually replaced by a **mineral lattice made of calcium and phosphate**.
* 🔬 Scientists are working on a method to **grow bones outside the body** using a patient's own stem cells, a mineral lattice, and a bioreactor that **simulates conditions inside the body**.
* 🚀 Astronauts in space must exercise constantly to prevent bone loss, as the lack of skeletal strain increases **osteoclast activity**, breaking down bone faster than **osteoblasts can rebuild it**.
* Current bone repair methods, such as using metal or donor bones, have limitations, including the **risk of infection or rejection by the immune system**.
* 🐖 Lab-grown bones have already been successfully implanted in animals, and **human trials may begin as early as 2016**.
* 🔬 "An ideal solution would be to **grow a bone made from the patient's own cells** that's customized to the exact shape of the hole, and that's exactly what scientists are currently trying to do."
* The process involves **extracting stem cells from a patient's fat tissue**, modeling the missing bone using **3D printers or decellularized cow bones**, and placing the patient's stem cells on the mineral lattice in a **bioreactor**.
* 🏥 If successful, this method could **revolutionize bone repair**, offering a **personalized, biocompatible solution** for conditions like cancer removal, traumatic accidents, and genetic defects.

Can you grow a human bone outside the human body? The answer may soon be yes, but before we can understand how that's possible, we need to look at how bones grow naturally inside the body. Most bones start in a growing fetus as a soft, flexible cartilage. Bone-forming cells replace the cartilage with a spongy mineral lattice made of elements like calcium and phosphate. This lattice gets harder, as osteoblasts, which are specialized bone-forming cells, deposit more mineral, giving bones their strength. While the lattice itself is not made of living cells, networks of blood vessels, nerves, and other living tissues grow through special channels and passages. And over the course of development, a legion of osteoblasts reinforce the skeleton that protects our organs, allows us to move, produces blood cells, and more. But this initial building process alone is not enough to make bones strong and functional.

If you took a bone built this way, attached muscles to it, and tried to use it to lift a heavy weight, the bone would probably snap under the strain. This doesn't usually happen to us because our cells are constantly reinforcing and building bone wherever they're used, a principle we refer to as Wolff's Law. However, bone materials are a limited resource, and this new, reinforcing bone can be formed only if there is enough material present. Fortunately, osteoblasts, the builders, have a counterpart called osteoclasts, the recyclers. Osteoclasts break down the unneeded mineral lattice using acids and enzymes so that osteoblasts can then add more material. One of the main reasons astronauts must exercise constantly in orbit is due to the lack of skeletal strain in free fall. As projected by Wolff's Law, that makes osteoclasts more active than osteoblasts, resulting in a loss of bone mass and strength.

When bones do break, your body has an amazing ability to reconstruct the injured bone as if the break had never happened. Certain situations, like cancer removal, traumatic accidents, and genetic defects, exceed the body's natural ability for repair. Historical solutions have included filling in the resulting holes with metal, animal bones, or pieces of bone from human donors, but none of these are optimal as they can cause infections or be rejected by the immune system, and they can't carry out most of the functions of healthy bones. An ideal solution would be to grow a bone made from the patient's own cells that's customized to the exact shape of the hole, and that's exactly what scientists are currently trying to do. Here's how it works. First, doctors extract stem cells from a patient's fat tissue and take CT scans to determine the exact dimensions of the missing bone. They then model the exact shape of the hole, either with 3D printers,

or by carving decellularized cow bones. Those are the bones where all of the cells have been stripped away, leaving only the sponge-like mineral lattice. They then add the patient's stem cells to this lattice and place it in a bioreactor, a device that will simulate all of the conditions found inside the body. Temperature, humidity, acidity, and nutrient composition all need to be just right for the stem cells to differentiate into osteoblasts and other cells, colonize the mineral lattice, and remodel it with living tissue. But there's one thing missing. Remember Wolff's Law? An artificial bone needs to experience real stress, or else it will come out weak and brittle, so the bioreactor constantly pumps fluids around the bone, and the pressure tells the osteoblasts to add bone density. Put all of this together, and within three weeks, the now living bone is ready to come out of the bioreactor.

and to be implanted into the patient's body. While it isn't yet certain that this method will work for humans, lab-grown bones have already been successfully implanted in pigs and other animals, and human trials may begin as early as 2016.

How to grow a bone - Nina Tandon

TED-Ed’s mission is to create lessons worth sharing. Feed and expand your curiosity with our award-winning animated shorts - published on YouTube and available with supplemental learning materials on ed.ted.com.

Want to suggest an idea for a TED-Ed animation, nominate an educator or animator? Visit our website at: http://ed.ted.com/get_involved.

Consider backing us on Patreon. By doing so, you directly support our nonprofit mission to create free, high-quality educational content: https://www.patreon.com/teded

For more information on using TED-Ed content for commercial purposes (e.g. employee learning, in a film, or in an online course), please submit a Media Request using this link: https://media-requests.ted.com/


TED-Ed

Researchers are exploring the possibility of growing human bones outside the body, similar to their natural development.

Bones start as flexible cartilage in a fetus, which is then replaced by a spongy mineral lattice through the action of osteoblasts.

The balance between osteoblasts and osteoclasts is crucial for bone strength, and factors like microgravity in space can disrupt this balance, leading to bone loss.

Innovative Solutions for Bone Reconstruction

The body has a remarkable ability to heal broken bones, but certain situations can overwhelm this natural repair.

Historical methods for filling bone gaps have been suboptimal, leading to infections and immune rejection.

Scientists are now working on a solution by using a patient's own stem cells and 3D-printed or decellularized cow bones to grow customized, living bones, with a bioreactor simulating body conditions and applying fluid pressure for bone density.

Lab-grown bones have been successfully implanted in animals like pigs, showing potential for human application.

Human trials for this method may start as early as 2016.

The effectiveness of lab-grown bones for humans is still uncertain.
