Bandgap Reference Generator Circuit Design and Implementation

The bandgap reference generator requires careful design to ensure stable operation and effective startup.

### Transistor-Level Bandgap Reference Generator Circuit Design
* 🔌 The bandgap reference circuit requires a minimum supply voltage of **1.4 to 1.5 volts**, with a typical supply of **1.8 volts**, for correct operation.
* ⚙ The circuit includes two branches, one with a diode and the other with a larger diode and a resistor, and an amplifier to **equalize the voltages** in these branches.
* 🔋 The amplifier's input common mode range is crucial, with **PMOS input pairs preferred** due to their **higher margin at worst-case conditions**.
* 🔊 The circuit features an amplifier that derives its current from the **bandgap itself**, a common technique in **bandgap reference design**.
* 🎛 The load devices can be implemented using a current mirror, with a second stage acting as a **level converter** due to the amplifier's **output common mode limitation**.
* 📊 Stability and frequency compensation are key considerations, with a **simple dominant pole compensation** added to the circuit.
* 🚀 The startup circuit, typically generating a few hundred **nanoamperes to a few microamperes**, is crucial for initiating the **bandgap circuit**.
* 🔒 The startup circuit includes a mechanism to **stop current dumping** when the bandgap circuit has successfully started, usually by **comparing the bandgap current with a reference current**.

Hey guys, in the last few videos, we have looked at different concepts related to band gap reference generator circuits. In this video, we will consider some transistor-level implementations complete with amplifier and startup circuit. Let's start with the branch which will generate our final output. So, we already know that V_PET voltage will appear across resistor R4, and the V_SEAT voltage would appear across diode D3, and the current in this branch would be a V_PET current. And we would require a V_PET current source in the form of a PMOS transistor on the top of reference voltage. Now, from this branch, we can calculate the minimum supply voltage required for correct operation. A typical bandgap reference voltage is 1.25 volts, and we would require a few hundred millivolts across the transistor to keep it in saturation. So, in total, we will require 1.4 to 1.5 volts of supply for this circuit to operate correctly. So, let's assume our typical supply to be 1.8 volts with some variations around it.

so this is a very commonly used analog supply range for large imagery process nodes. Now let's insert the core of the band gap. So we have two branches here, one containing only a diode and the other containing a larger diode and a resistor. And we know if we make V N and V P equal, then the current flowing in these two branches will be P tat. And in order to make these two voltages equal, we need to now insert an amplifier. Now there are two flavors of amplifiers available depending on the type of the input transistors. So we can either have P Mo's input tester or so-called PDF or n MOS input raster or so-called. And if now there are many factors deciding which kind of dip pair should be used, and one of the most important is input common mode range. Input voltage in this case is C, that voltage across diode. Let's assume diode voltage at room temperature to be around 700 millivolts and see Ted slow to be minus 2 milli volt per degree Celsius. So now we can calculate the

diode voltage whole range of temperature. So, we have amplifier input voltage ranging from around 850 millivolts to 450 millivolts. Now, lower input voltage is better for PMAs because it has more margin, and higher input voltage is better for AMAs. So, worst-case condition for PMAs would be 850 millivolts, and for AMAs would be 450 millivolts. So, now let's see how much margin these two display have at their respective worst-case conditions. So, we see that even if we consider the worst-case supply of 1.62 volts, the margin that PMAs has is 770 millivolts, which is considerably higher than worst-case AMAs margin, which is 450 millivolts. And that is precisely the reason that most of the conventional bandgap circuit used PDF as the input pair. So, let us also stick with PDF. So, in this implementation, we are passing the amplifier by the P that current of band gap itself, and it is a very common

technique, although by no means the only technique now coming to load devices, we have a few options available here as well. We can use a current mirror as a load stage, or we can go for more advanced options like folded cascode. Both options are used frequently in practical design. Let's stick to the current mirror in this video purely because of its simplicity. So, here is our amplifier, but because of the output common mode limitation of this amplifier, we cannot simply connect its output directly to the Pima stages. So, we need another stage in between. So, here is our second stage. Now, notice that the second stage is not actually a gain stage because the load device is a low impedance diode connected transistor. So, this is more of a level converting stage. Next, knowledge snake stability and frequency compensation. So, how many poles are there in this circuit? So, if we attach one pole to one node in the signal path, there are four poles. Notice that I am ignoring the pole at the V end node. There are two reasons for it. First reason is that in normal mode

diode offers a very low impedance, so we can assume VN to be Kelly constant. The second reason is that this vnode comes in the positive feedback loop, while in a normal mode, it is a negative feedback, which will dominate over positive feedback. Coming back to our four pools, the second and fourth Pole would be high-frequency pool, and this is because of the presence of low impedance. They're connected transistors. Note one is the high impedance node, so this pole will be a low-frequency Pole. Ignoring the diode impedance again, that third pole will be decided by the value of r1. Typical value of r1 is few tens to few hundreds of kilo ohms, so in its higher limit, it will just start to deteriorate the phase margin of the system. So one can rightly argue that we don't need a compensation here because it is effectively a single pole system. There is only one dominant pole, but better safe than sorry. Let's anyway put a simple dominant pole compensation here and to complete the

circuit. Let's also indicate the condition at the input of the amplifier. Okay, so now we have put the core of the circuit in place. The only remaining piece in the puzzle is startup. So we know that in order to start the circuit, we need to insert current at appropriate nodes. So let's first consider how to generate that startup current itself. Startup current need not be very accurate, but it must guarantee the current generation, that is, it's all startup. We have seen once a circuit in the beginning of theta 3, that video. It is a diode-connected transfer followed by a resistance. The circuit will carry current as soon as there is a voltage drop across this resistor. This condition is met as soon as the supply voltage is higher than the threshold voltage of this transistor. So this is a very simple and reliable way of generating current at even very small supply voltages. Current in this branch is approximately given by this equation, which is VDD minus VG's of this transfer divided by the resistance value. So we can control this current by controlling DISA distance. Now sutter

current is usually a few hundred nanoamperes to a few microamperes. So, in order to achieve that level of current, the resistance needs to be very big. For example, if we assume one microampere of startup current and 0.8 volts across the transistor, then for typical supply voltage, this ratio needs to be one megaohm. So, it's not unusual to have several megaohms of resistance in this branch. Now, a big laser can have a significant area penalty. So, in many area-sensitive designs, this resistance is implemented by the means of transistors. One common way is to connect several long-channel and merged devices in series, and their gate is connected to the supply. In other words, it's always on weak and mas. The disadvantage of this scheme is larger PVT variation in startup current. So, keeping this in mind, let's proceed with the distance in this video. The next logical question is where to insert the current. We want positive feedback to dominate in the beginning, so we can insert current into the VN node. But since the amplifier derives the

current from the bandgap itself. We also want these FEMA says to carry the current. So, one way of doing this is to insert the current into this node, but an equally valid way of inserting the current into these P masses is to take out the current from this node but insert the current into this node. As a matter of fact, in principle, all of these techniques can be designed to work, but most of these nodes will result in excessive peaking in the output voltage. This is because even if we insert current in these branches, the amplifier will wake up by its own time constant, which is determined by its dominant pole compensation. In fact, the smoothest possible startup is achieved by inserting the current into this compensation capacitor. So, in other words, waking up your slowest node first is the best policy here. So, we mirror the current and dump this current into the capacitor. The next step is to stop this dumping when the circuit has successfully started. The most common way is to sense the current in the bandgap circuit and stop when the current is big enough. So,

this is one way of doing it. So, this branch is comparing the static current with band gap current. When there is no current in the band gap, this node is pulled by the startup current, and the inverter output is zero. Hence, this PMO's is on. When sufficient current builds up in the bandgap, the load is pulled low, and the current dumping is stopped. So, this scheme also puts an upper limit to the startup current across all PV T corners. The startup current must always be less than the final bandgap current. A commonly used value of maximum ratio of bandgap current to static current is 4 to 5. In other words, the maximum startup current at a given PV T corner should be 4 to 5 times less than the bandgap current. Now, one may be tempted to turn off the starter current generation branch as well along with this branch to save the power, but I must caution against it. It should never be done. If it is done, then it may result in a stuck state in the circuit. In that stuck state

the bandgap circuit is still not on, but the startup circuit has turned off, so we see that the startup circuit consumes currents in these two branches, which is always present. This may be a big issue in low-power circuits, but if low power is absolutely critical and you can trade some accuracy for the power, then there is another way. Remember we said that we can start the circuit by inserting the current into this branch. So, if we replace this transfer by a register, then this resistor would act as a startup circuit. As the supply ramps up, this register forces this amplifier node to go up as well, and this would force current in the two branches of the amplifier. This current would eventually force current into these two diode branches, and this will cause the circuit to start up. But now, because of this resistance, the power supply and common mode rejection of this amplifier will not be very good. Also, the basket of amplifiers will change with the supply, which will change its GM with the supply. This variation will cause any crises in the final bandgap output voltage, but for ultra-low power

application. This technique can be considered. Also, notice that this technique works only for the p-type differential input pair. As a last step, let's consider some options we have in the output generation stage. We know that we can generate the output voltage in these two branches as well using these stages. Will obviously save the area and power that we spent in this final branch. So, is there any advantage of using this dedicated reference branch at all? In fact, there is an advantage. Notice that this reference branch is out of the feedback loop, so any change in the output capacitance does not change the stability of the system. Now, this can be a crucial factor if you are not sure about your output capacitance value. Now, let's say we know our output capacitance value rather well and we are interested in selling some area and power. So, we can get rid of this final branch. Now, we have two options in hand. Is there any preference there? In fact, there is. Recall that for start-up, we want V EndNote to come up quickly, so we

would like to avoid any delay in this branch, and for that reason, they will tab the output from the other branch. Actually, there is another option available; there are subtle advantages in shorting these two nodes out. So, in this case, only one node is available, right? So, in this video, we have considered a transfer level schematic of a bandgap reference generator, except for the fact that a real practical circuit does not often use the diodes; they use BJTs. So, we will take BJTs in our next video. For this video, post your comments below, and thanks for watching.

#26 Band-gap Reference Circuits - Circuit Implementation

Analog Snippets

Transistor-Level Implementations of Band Gap Reference Generators

The video discusses transistor-level implementations of band gap reference generator circuits, focusing on the output branch and the required supply voltage.

A typical bandgap reference voltage is 1.

The video also explores the use of different amplifier types for input transistors, highlighting the advantages of PMOS over NMOS in terms of input voltage margin.

Load Techniques and Circuit Design for Amplifiers

Current mirrors and folded cascodes are common load stage options for amplifiers, with the current mirror being chosen for its simplicity.

A second stage is added for level conversion, as the output common mode limitation of the amplifier prevents a direct connection to the Pima stages.

The circuit has four poles, with the second and fourth being high-frequency due to low impedance transistors, and a dominant pole compensation is added for stability.

Startup current for transistors is typically in the microampere range, requiring high resistance values, often in the megaohm range.

Area-sensitive designs may use transistors in series to implement this resistance, but this can lead to larger variations in startup current.

The smoothest startup is achieved by inserting current into the compensation capacitor, waking up the slowest node first, and the current dumping is stopped once the circuit has successfully started.

Startup Current Control in Bandgap Circuits

The branch compares static current with bandgap current, using the startup current to pull the node low and turn on the PMO.

The startup current is limited to 4-5 times less than the bandgap current to prevent a stuck state in the circuit.

An alternative startup method using a resistor can trade accuracy for power, but may lead to variations in the amplifier's common mode rejection and output voltage.

Output Generation in a Bandgap Reference Generator

The technique discussed is specific to the p-type differential input pair.

The dedicated reference branch offers stability by being out of the feedback loop, crucial for uncertain output capacitance values.

There are options to eliminate this branch for area and power savings, with a preference for tapping the output from the other branch to avoid startup delays.
