Hello! Actually, I was planning to continue the visual storytelling series, but I ran into some problems along the way. I managed to get through four episodes and recorded the fifth, but I haven't uploaded it yet. It's been a bit challenging, and since it's dragging on, the video will eventually be uploaded, but for now, I want to address some of the issues before continuing with the writing. So, in this brief moment, I want to introduce something I've been working on lately. It's called Solon Bot. As you can see, it works with KakaoTalk. Here's how it operates: you enter a dollar sign followed by a keyword, and it provides a summary of that keyword. You've seen it, right? It summarizes like this. I've introduced Solon Bot in another group chat, and many people have had the chance to try it out. I'm grateful for that.

제가 만든 걸 써 주셔서 정말 감사한데, 그러면 이제 저한테 물어보시는 질문들이 뭐냐면 첫 번째로, 이 카카오봇 어떻게 만드냐가 첫 번째고, 두 번째로 이 세 줄인데 어떻게 이 내용만 뽑게 하냐는 것입니다. 그러니까 보통 제미나이, 피든, 클로드는 이 세 줄 요약을 한다고 부탁을 해도, 이 세 줄만 쓰는 게 아니라 앞뒤로 이제는 덧붙이는 경우가 많아요. 그리고 가끔 이상한 키워드를 주면 이상한 말을 많이 하고, 그런데 상대적으로 안정적으로 어떻게 이런 식으로 세 줄 요약으로 맞출 수 있냐는 질문입니다. 그러니까 원하는 내용만 뽑게 할 수 있냐는 것이죠. 카톡 봇을 만드는 것은 이번에 알려 드리고, 요약 아웃풋을 만드는 것에 대해서는 다음에 얘기해 볼 거예요. 근데 솔직히 카카오 봇을 만드는 법이나 이런 것은 솔직히 다 나와 있는데, 그분들도 이제...

Since there are many developers, I think they were unfamiliar with Kakao bots because they haven't seen them often, which is why they asked me questions. However, honestly, if they look at it just a little bit, they would understand it right away. Now, I don't know if there are people who are curious, but first, I will introduce my Solo Bot and also briefly mention the series that had some issues. So, what I'm going to talk about today is the hardware structure of the Solo Bot and its features.

To start, I used a Raspberry Pi. Is it Raspberry Pi 3? Yes, I used that. I utilized a 1-core, 1-ram model that I had at home. As many of you know, it is a well-known small mini-computer. On top of that, I set up a Docker environment. So,

I placed the Fast on top of the Zveri 3. So, what does this Fast do? It serves as a fun tool. It's not that there's a very special reason; I just thought that, compared to what I was using, it was somewhat more efficient in terms of cost, which is why I chose to adopt the Dami Nari. Now, is this the only thing that allows the smartphone bot to operate? No, that's not the case. You need a smartphone for this. An Android tablet might also work; I haven't tested it, but it should be possible. So, what did I install here? I installed an app called Messenger Bot AI. This is an application that helps with certain effects. When you receive something on KakaoTalk, it can automatically respond to it. So, the Messenger Bot communicates with KakaoTalk. This is the function of the Solon Bot.

This is a rough structure. So, if there is a keyword starting with dollar in KakaoTalk, it won't work if the dollar sign is not present at the front. Now, when a keyword starting with dollar comes in here, the messenger bot sends that keyword. Then, what the Fast API does is request a summary using the keyword. Naturally, the API will send back the content of the keyword summary. Then, the Fast API takes the keyword summary content and sends it back to the messenger bot. Now, the messenger bot is a bit messy, but this is KakaoTalk. So, I send the keyword dollar from my computer. It's the dollar keyword. When I send the dollar keyword, I have a smartphone that I used in the past; it's an empty phone that I direct the computer towards.

Please send the keywords to the FastAPI. Then, the FastAPI will request a keyword summary from the Gemini AI. After receiving the summarized keywords from Mina, the FastAPI will send that summary back to the messenger. Consequently, the summarized information will arrive via KakaoTalk messenger. Ultimately, what I will see is the summarized KakaoTalk message. This outlines the general structure of the Solon bot.

Now, if we consider the keywords without the dollar sign, there will be no response. This is because I instructed it to send keywords with the dollar sign, so it filters them out. Since this is based on JavaScript, if the dollar sign is not present, it does not perform any action. As a result, it does not send anything to the messenger because there are no dollar keywords. Therefore, I will not receive the summarized KakaoTalk message. On the other hand, if the dollar sign is present...

When you send the word, it summarizes the entire content and sends it via KakaoTalk. So, at least two devices are needed: a smartphone, which should be an Android, and I used a Raspberry Pi 3. If you have another mini computer or low-power computer that you can personally use, you can use that as well. The reason I don't recommend using a desktop is that it needs to run 24 hours a day, like a server. However, desktops often come with GPUs or have higher CPUs, which means they consume more power even when idle. On the other hand, Raspberry Pi is known for being a low-power computer, so it has less burden when running continuously. So, I used the Python code with the hack function on Raspberry Pi 3 to carry out this task as a Solon bot.

If you have a smartphone, you might think that you could just place a messenger bot on it. It is likely possible since smartphones, including Android devices, are a type of Linux, and there are a few special applications that utilize this. I tested whether it was possible to run Docker on those special applications a few years ago, and I believe it still can be done. By using Docker, you could deploy FastAPI and make fun requests. This means you could run both a messenger bot and FastAPI on your smartphone. However, since smartphones are not originally designed for this purpose, it would be quite cumbersome. So, having a server-type computer or a mini computer that can be purchased directly from China wouldn't be a bad option either.

If you can install just the domain here, it will work. It's not difficult. So, we'll stop here for today, and next time I'll talk a bit more about how to summarize this in three lines. I think I've covered the hardware and the general structure to some extent. People are most curious about how to summarize it in three lines, so I'll discuss that next time as well. Because I'm currently using Visual Studio, I need a little more time, so I'll fill that in. Thank you for listening today, and I'll see you next time.
